NEW Doosan G570 - 450KW Tier 4 FINAL CARB Diesel Power Module
NEW Doosan G570 Tier 4 Final Power Module
New Doosan G570WCU-2B-T4F Rental Grade Power Module - Powered by Cummins X15 Engine - Prime Duty Rated at 456KW, 570KVA, 60Hz, 480V (selectable), 1800RPM - Includes Engine Driven Radiator, Digital Controller, Heavy Duty Air Cleaners, 650 Gallon Fuel Tank, Link Board Panel, Breaker, Battery Charger - Trailer Mounted in Sound Attenuated Enclosure - EPA Tier 4 FINAL and CARB Emissions Compliant - 0 Hours - Identical 2nd Unit Available
|Enclosure / Portable||Mobile/Rental|
|Serial Number Prefix||505|
The G570 power node features a Cummins 15-liter X15 T4F engine. This generator is powered by a Doosan DL08P diesel engine that meets Tier 4 Final emissions standards. The engine is designed to provide high efficiency and durability in demanding applications. It has no minimum load requirements in working temperatures down to -13° F (-25° C). Its upsized alternator allows for better motor starting capabilities, superior reaction to harmonics and improves overall alternator life.
Ideal for rental, construction and special event applications, the G570WCU-2B-T4F generator has a prime power rating of 570 kVA (456 kW) and voltage configurations of 480V, 208V and 120/240 1Ø. The G570 can run 24 hours without refilling the diesel or DEF tanks in most applications.
The generator features a user-friendly control panel that allows operators to monitor and adjust various parameters such as voltage, frequency, and engine speed.
Frequently Asked Questions About Doosan G570 Power Module
Does the Doosan G570WCU-2B-T4F require regular maintenance?
The system requires minimal maintenance and is easily accessible on the front of the machine. All user interface components, such as the controller, link board panel, and convenience receptacles, are located on the rear of the machine for added ease of operation.
Is the Doosan G570 Power Module equipped with sound attenuated enclosure?
The G570WCU-2B-T4F is housed in a sound attenuated enclosure that reduces noise levels and makes it suitable for use in noise-sensitive areas.
|Doosan Power Modules Brochure||3.2 MB||Download|
